to order HSS7009-C-T-P4S-UL machine tool main spindle bearing Dimension:45x75x16mm,steel ball,sealed

Place of Origin : Germany

Brand Name : FAG

Model Number : HSS7009-C-T-P4S-UL

Certification : ORIGINAL

Price : NEGOTIATION

Packaging Details : Standard carton

Delivery Time : 2 days

Payment Terms : T/T

Supply Ability : 1000PCS/MONTH

MOQ : 2PCS

Contact Now

FAG bearings HSS7009-C-T-P4S-UL adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances, steel ball
d: 45mm D: 75mm B: 16mm
Type:	HSS	Bearing with small balls ceramic balls sealed
Dimension series:	70	Medium series
Dimension（dxDxh）		45x75x16mm
Contact angle:	C	C =15° E = 25°
Cages:	T	Plastic fiber cage, outer ring guided
Precision:	P4S	P4S FAG standard, reference to DIN620, higher than P4
Bearing arrangement:	U	single bearing, universal assemble
Preload:	L	light preload

HSS7009-C-T-P4S-UL High Precision Ball Bearing HSS7003.C.T.P4S.UL Machine tool main spindle bearing

HSS7009CTP4SUL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 15 degrees contact angle and Phonetic cage, bearing is P4 quality and made in Germany

Item: HSS7009-C-T-P4S-UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel ball

Quality: P4 Grade

Dimensions: 45mm x75mm x16mm /Metric

ID (inner diameter)/Bore: 45mm

OD (outer diameter): 75mm

Width/Height/thickness: 16mm

Size:45 x 75 x 16mm

Quantity: One Bearing

Dynamic load rating Cr: 12900 N

Static load rating Cor: 12200 N

Limiting Speed:

Grease Lubrication: 24000 RPM

Oil Lubrication: 0 RPM

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

to order HSS7009-C-T-P4S-UL machine tool main spindle bearing Dimension:45x75x16mm,steel ball,sealed
