B71911-E-T-P4S-UL Machine tool main spindle bearing 55x80x13 mm, single universal arrangement,P4 Grade

Product Categories
JinHang Precision Bearing Co.,Limited
Contact Now

B71911-E-T-P4S-UL Machine tool main spindle bearing 55x80x13 mm, single universal arrangement,P4 Grade

  • 1
  • 2

Place of Origin : Germany

Brand Name : FAG

Model Number : B71911-E-T-P4S-UL

Certification : ORIGINAL

Price : NEGOTIATION

Packaging Details : Standard carton

Delivery Time : 2 days

Payment Terms : T/T

Supply Ability : 1000PCS/MONTH

MOQ : 2PCS

Contact Now

FAG bearings B71911-E-T-P4S-UL

adjusted, in pairs or sets, contact angle α = 25°, restricted tolerances

d: 55mm D: 80mm B: 13mm

Type:

B

Standard Steel balls

Dimension series:

719

Light series

Dimension（dxDxh）

55x80x13mm

Contact angle:

C

C =15° E = 25°

Cages:

T

Plastic fiber cage, outer ring guided

Precision:

P4S

P4S FAG standard, reference to DIN620, higher than P4

Bearing arrangement:

U

single bearing, universal assemble

Preload:

L

light preload

B71911-E-T-P4S-UL High Precision Ball Bearing B71911.E.T.P4S.UL Machine tool main spindle bearing
B71911.E.T.P4S.UL FAG High Speed Angular Spindle Ball Bearing
25 degrees Contact Angle
P4 Grade
55mm x80mm x 13mm
Made in Germany

B71911.E.T.P4S.UL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 25 degrees contact angle and Phenolic cage, bearing is P4 quality and made in Germany

Item: B71911.E.T.P4S.UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel

Quality: P4 Grade

Dimensions: 55mm x80mm x 13mm /Metric

ID (inner diameter)/Bore: 55mm

OD (outer diameter): 80mm

Width/Height/thickness: 13mm

Size:55 x 80 x 13 mm

Quantity: One Bearing

Dynamic load rating Cr: 21600 N

Static load rating Cor: 193000 N

Limiting Speed:

Grease Lubrication: 15000 RPM

Oil Lubrication: 24000 RPM

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

B71911-E-T-P4S-UL Machine tool main spindle bearing 55x80x13 mm, single universal arrangement,P4 Grade
